Manlids

Pelican offers a complete range of manlids. This manlid selector helps you to select the right manlid suitable for your application within a few clicks. If the requested manlid cannot be found or is not available, please contact our sales or engineering department.

Pelican Worldwide - Manlids

Manlids

Manlids are used on tank containers, rail tank cars and road tankers to be used as a man way. Find our selection of manlids and manlid parts below

Manlid Assemblies

A manlid clamp is fitted to the manlid as a safety precaution against opening when the tank is under pressure. All our manlids clamps are manufactured to tight specifications using premium quality materials that guarantee safe and secure operation under all circumstances.

Technical details
Visit our webshop

Manlid Clamps

A manlid clamp is fitted to the manlid as a safety precaution against opening when the tank is under pressure. All our manlids clamps are manufactured to tight specifications using premium quality materials that guarantee safe and secure operation under all circumstances.

Technical details
Visit our webshop

Manlid Cover

The manlid cover is designed to use on chemical and foodstuff liquid tank containers. Our cover is standard double skin lid, which means we manufacture our manlid dome of 2 plates with air in between them.

Technical details
Visit our webshop

Manlid Neckring

A manlid neckring is made of a cut steel plate, which is a very strong material. The straight neck thickness can be 6 to 8mm.

Technical details
Visit our webshop

Manlids technical details

Manlid Assemblies

Parts of our manlid in which will be in contact with chemicals are manufactured in Stainless steel 316 and 316L. Non-contact parts are manufactured in Stainless steel 304.

Approval & standards:
Design Codes & Approvals
ASME VIII Div.1, RID/ADR, IMDG, Lloyds, EN14025
Temperature
Design Temperature -40ᵒC ( -40ᵒF) to 205ᵒC ( 401ᵒF)
Material
SS316 Electro polished.
Manlid Clamps

We manufacture manlids of all types and sizes for tank containers and tank trailers. All our manlids clamps are manufactured to tight specifications using premium quality materials that guarantee safe and secure operation under all circumstances.

Manlid Cover

Parts of our manlid in which will be in contact with chemicals are manufactured in Stainless steel 316 and 316L. Non-contact parts are manufactured in Stainless steel 304.

Approval & standards:
Design Codes & Approvals
ASME VIII Div.1, RID/ADR, IMDG, Lloyds, EN14025
Temperature
Design Temperature -40ᵒC ( -40ᵒF) to 205ᵒC ( 401ᵒF)
Material
SS316 Electro polished.
Manlid Neckring

Our neck and compensating ring are pressed in one piece from cut steel plate, we choose this method because stainless steel pressing is stronger than welding.

Approval & standards:
Design Codes & Approvals
ASME VIII Div.1, RID/ADR, IMDG, Lloyds, EN14025
Temperature
Design Temperature -40ᵒC ( -40ᵒF) to 205ᵒC ( 401ᵒF)
Material
SS316 Electro polished.
